دستگاه حالت دهنده علفها Krone EASYCUT B 1000 CV COLLECT

Illumination
Load Sensing
EASYCUT B 1000 CV COLLECT
Krone disc mower combination
Technical data
+Disc mower combination for three
point attachment with CV high-performance steel
tine conditioner and cross conveyor belts
+Working width 2 x 3,600 mm
+Working width in conjunction with front disc mower
disc mower 9,300-10,100 mm
+Transport width 2,950 mm
+Two mowing drums
six mowing discs
(per mowing unit)
+Work capacity approx. 10-13 ha/h
+Power requirement from approx. 150 KW (200 HP)
depending on harvesting conditions!
+Own weight approx. 3,880 kg
+Lower linkage mounting Cat. III/IV
Basic equipment mower frame
+Krone DuoGrip mower suspension
+Adjustable collision protection
+Hydraulic cutterbar relief
Combi Float
+Outer and front mower guard
Foldable
+Hydraulic cylinders integrated in the extension arm
cylinder for working width adjustment
+Automatic maintenance of the transport height
height of 4 m (with approx. 25 cm ground clearance)
+Double-acting
hydraulic folding
process
+Space-saving in transport position
can be parked
Drive train
+PTO shaft-gearbox combination
+Tractor PTO shaft (1 3/8"
6-piece)
incl. overload clutch
+PTO shaft speed 1,000 rpm
+Drive train with freewheel
+PTO shaft lubrication interval 250 h
Cutter bar
+SafeCut mowing disk safety device
+SmartCut mowing disk arrangement
+Lubricated for life
+Welded all round
+Large cutter bar cross-section
+Hardened skids
+Satellite drive
+Full swivel range of the blades of
360°
Conditioner
+CV high-performance conditioner with
V-shaped
handle-mounted and hardened
hardened steel tines (diameter 64 cm)
+Gearbox for two conditioner speeds
speeds
+Conditioner baffle plate adjustable in 7 steps
adjustable without tools
+Lateral swath plates for quick changeover
changeover from wide to swath delivery
Swath forming
+Individually switchable
910 mm wide
cross conveyor belts with infinitely adjustable
adjustable belt speed (1400)
+Cross conveyor belt with internal frame
frame (no wear-prone seal required)
sealing necessary
change possible)
+Adjustable cross conveyor belt baffle plate
+Guide plates for wide depositing
Further equipment
+Removable blade box
+Operation via preselection control box and
tractor-side control valves
or via
ISOBUS
+LED lighting for light/brake light
incl. warning signs
+Standard operation electrical preselection
operation manually preselectable limiting
of the telescoping path on the extension arm
Necessary hydraulic connections
Load-sensing system (P-T-LS)
(side-independent folding of the cross
conveyor belts)
+Direction of rotation "A" (all discs turn to the
to the center)
CV conditioner equipped
with litter performance-enhancing
(closed) conditioner tines
+Quick knife lock
+Driver training for 2 participants Registration
and possible dates via your
KRONE service and sales partner
f.more information see chapter S&P
+Swath accelerator rollers for the production of
particularly narrow swaths (manually operable)
manually operated)
2xdouble-acting +
fast belt
